48-PORT PATCH PANEL CAT6

• Meets or exceeds TIA/EIA-668-B.2-1 Category 6 Component Performance Specification.
• Tested for NEXT, PS-NEXT, FEXT, Return Loss, and Attenuation up to 360MHz.
• Includes Cable Ties, Cable Organizer, and Mounting Hardware.
• Occupies 1U space on the Rack

The NEXION 48-PORT PATCH PANEL CAT6 has 48 ports in the front which are hard-wired to 48 terminals at the back. The ports are numbered. The terminals at the back are colour-coded for easy termination of wires.

The cables from the different Work Stations in the network terminate at the back of the NEXION 48-PORT PATCH PANEL CAT6. The termination is done on the Patch Panel terminals with a Punch-Down tool. The colour-coded terminals ease the cable termination. The terminated cables are already hard-wired to the different ports of the Patch Panel.

At the front of the NEXION 48-PORT PATCH PANEL CAT6, the Patch Panel ports are “jumpered” to the network switch using NEXION patch cables (or “Fly-Cables” or “Fly-Leads”). A direct connection, swappable when necessary, has thus been made from the Work Station / Faceplate to the Network Switch. The Patch Panel facilitated this.

The advantage of using the NEXION Patch panel is that it allows manual monitoring, testing, switching, and other maintenance activities to be handled quickly. This is because the cables in the front that connect to the more permanent cables in the back are easily swappable so that changes can be made quickly and easily when necessary. You do not have to re-run cables every time you want to maintain or swap locations.
